STANDARD FEATURES:
- Wall
Mounted
- Tiltable
Display (Back and Forth) for those Sunny Days
- Dual
Depth Display (Depth & Depth+Offset).
- Martin-Decker
style Large Tension Dial Display.
- Field
depth calibration (Per 1000 units).
- 3
Operator configurable (Audio/Visual) alarms for depth,
tension, tension spike, & speed.*
- 120VAC
or 12VDC operation.
- Digital
Depth readout (Feet/Meters).
- Digital
Speed readout (Feet/Meters, per Min. or Hr.).
- Signature
direction arrow.
- Digital
Tension readout with configurable Tension/spike gauge
(differential & absolute Tension, Lbs./Kgs.).
- Operator configurable English/Metric Depth, Tension & Speed
units (In any combination).
- Activity Log for activity recording at up to 4 times a second.
Including Depth, Tension, Tension Spike, Speed, and Alarm
Status. (Accessible by downloading to a USB flash-drive.)
- Up
to 4GB of onboard space for logs (Tattletale files),
easily accessible by copying them to a USB thumb drive (
.csv format).
- Authorization
Security to lock out one or more changes to the
following: Depth Cal., Alarms, Encoder Settings, Tension
Cal., Units Changes, Time Set, Networking. Automatic
Deletion of Logs. (Accessible via a user set password).
- Intuitive
and elegant operator interface with remote
- Output
for logging system (Depth/Tension) (Warrior®
System
Compatible). Including Tension Output for easy Warrior®
System Tension calibration.
OPTIONS:
- *(Optional)
Relays Package (2 normally open/normally closed relays).
Note:
Relay
triggering is tied to alarms (operator configurable).
- (Optional)
Network Communication & Control Package:
- Pre-configured
wireless router.
- Windows
Remote Master for view/control.
- Windows
Remote Slave for view only,
- Handheld
- Android OS view only app
- Includes
Cables and Software.
|
|
